INSTRUMENTS

Code : V series

Oil-Free Piston Vacuum Pumps

? The ChemVak V series pumps use piston motion to produce a vacuum and are of such design that no oil has to be used to lubricate the pump. They are very easy to maintain, and can not only be used for vacuum creation but also for pressure supply. Because of the unique structure and advanced technology, the noise level of the pumps lies at comparatively low 48.7 to 60.0 dB. Thus, silent and effective work in the laboratory can be maintained ? The basic ChemVak V pump is suitable for non-corrosive materials, as used e.g. in the biological and food indust ? All pumps simply need the vacuum / pressure transformation set in order to convert the pump from a vacuum pump into a pressure pump. Thus, the ChemVak V series can be used for a large variety of purposes in the laboratory environment ? According to your needs you can choose from a large range of accessories Description Model V400 V600 V410 V610 VC300DC Mains Requirements 220-240V/50HZ 220-240V/50HZ 220-240V/50HZ 220-240V/50HZ DC12V Power (W) 80 190 80 210 35 Current (A) 0.4 1 0.4 1 3 Motor Speed (rpm) 1450 1450 1450 1800 1800 Ultimate Vacuum (mbar) 150 150 13 13 150 Flow Rate 1000mbar 34 L/min 52L/min 19 L/min 33 L/min 24 L/min 880mbar 31 L/min 46L/min 18 L/min 30 L/min 24 L/min 750mbar 29 L/min 40 L/min 16 L/min 27 L/min 24 L/min 600mbar 23 L/min 30 L/min 14 L/min 25 L/min 24 L/min 480mbar 19 L/min 30 L/min 11 L/min 20 L/min 24 L/min 350mbar 13 L/min 16 L/min 9 L/min 14 L/min 24 L/min 210mbar 4 L/min 6 L/min 6 L/min 12 L/min 24 L/min Outlet (mm) 8 8 8 8 8 Weight (kg) 5.2 8.6 4.1 3.5 3.5 Noise Level (dB) 60 52 50 52 50 Order No. 167400-22 167600-22 167410-22 167610-22 167330-22
Code : WH-SN Series

Rotary Vane Vacuum Pumps

Rotary vane pumps are traditional vacuum pumps, which can be used in a wide area including research and production. The WH series rotary vane pumps are ChemVak's standard vacuum pumps, which can be used individually or as a backing pump in combination with molecular pumps or diffusion pumps in order to create an extremely high vacuum. They are widely used in vacuum distillation, vacuum filtration, vacuum testing, vacuum freeze drying, vacuum plating, leak detection, vacuum packaging, vacuum sorption, and the like.

Product Features
? Compact structure and very good sealing. Even after shut-off there is no returning throughput
? Oil spout prevention
? Low noise
? Small casing
? Easy to transport
? High flow rate, which quickly leads to a stable ultimate vacuum
? High evaporation resistance
? Comparatively high chemical resistance
? High longevity and very low maintenance rate
? Low oil mist
? Oil-observation window for convenient oil inspection
? Gas ballast valve, which enables the user to let out a certain amount of gas
? Fuse for overcurrent protection
? Fulfills IP54 standards Description Type WH-12SN WH-24SN WH-36SN WH-8D WH-17D Pump Heads Single Single Single Double Double Flow Rate (L/min) 170 400 600 135 283 Ultimate Vacuum (mbar) 2.5×10-2 6.7×10-2 6.7×10-2 4×10-4 4×10-4 Power (W) 370 400 600 550 750 Noise Level (dB) <70 <70 <70 <54 <56 Oil Capacity (L) 0.65 1.3 1.5 1.1 1.5 Weight (kg) 12 24 28 27 31 Outlet Specifications 3/8" SAE Male; 1/4" SAE Male; 5/16" SAE Male DN25KF DN25KF DN25KF DN25KF Order No. 900103 900025 900035 900111 900112
Code : C Series

Diaphragm Vacuum Pumps and Systems

? All material of the ChemVak Chemical Resistant Diaphragm Pumps which has direct contact with gases is made of PTFE. It can be used in the chemical and petrochemical industry, the pharmacy industry and all industries that make use of chemical resistant vacuum processes, such as filtration, vacuum distillation, rotary evaporation, vacuum and centrifugal concentration, solid phase extraction, etc
? High price-performance ratio, reliable quality, special design, and low noise of 50 dB
? Huge product range can fulfill every need in the laboratory work
? An ultimate vacuum of 2 mbar can be created
? All pumps employ an overheating protection system, which shuts down the pump when the inner temperature is too hot and automatically starts the pump again when cooled down to a safe temperature. This guarantees a stable work of the pump and the safety of the user. You can integrate the chemical resistant diaphragm pumps into vacuum filtration systems and purchase a diverse variety of accessories for your pumps (see P.6 for further information). The special design prevents solid impurities from accessing the pump head and thus guarantees the longevity of the pump. The pressure level can easily be controlled and adjusted Description Model C400 C410 C510 C600 C610 Mains Requirements 220-240V/50HZ 220-240V/50HZ 220-240V/50HZ 220-240V/50HZ 220-240V/50HZ Work Mode Single In Succession In Succession Parallel In Succession Power?W? 95 95 245 270 245 Motor Speed (rpm) 1450 1450 1450 1450 1450 Ultimate Vacuum (mbar) 210 13 8 90 2 Flow Rate 1000mbar 34 L/min 25 L/min 34 L/min 60 L/min 34 L/min 880mbar 29 L/min 22 L/min 31 L/min 55 L/min 31 L/min 750mbar 25 L/min 20 L/min 29 L/min 51 L/min 29 L/min 600mbar 12 L/min 12 L/min 21 L/min 38 L/min 21 L/min 480mbar 6 L/min 7.5 L/min 16 L/min 32 L/min 16 L/min 280mbar 3 L/min 5 L/min 14 L/min 29 L/min 14 L/min Outlet?mm? 8 8 10 10 10 Weight (kg) 7 5 7 12.6 13.4 Noise Level (dB) 50 50 60 60 60 Order No. 169400-22 169410-22 169510-22 169600-22 169610-22
Code : P Series

Pressure Pumps

? Piston motion for pressure creation
? Oil-free technology
? Low noise level
? The P440 entails a gas tank, which enables long term gas provision Specifications Model P 320 P 420 P 440 Mains Requirements 220-240V / 50Hz 220-240V / 50Hz 220-240V / 50Hz Power (W) 85 125 125 Current (A) 0.4 0.6 0.6 Ultimate Pressure (without the use of a filter cup) 6.9 6.9 4.1 Ultimate Pressure (with the use of a filter cup) 5.5 5.5 4.1 Max. Flow Rate 0 bar 12 L/min 25 L/min 25 L/min 1.4 bar 9.5 L/min 23 L/min 23 L/min 2.0 bar 8 L/min 18 L/min 18 L/min 2.8 bar 8 L/min 16 L/min 16 L/min 4.2 bar 3 L/min 8 L/min 11 L/min Outlet (mm) 8 10 8 Motor Speed (rpm) 1400 1400 1400 Weight (kg) 4.1 5.2 8.4 Noise Level (dB) 50 60 50 Order No. 167320-22 167420-22 167440-22
Code : P540,P640

Compressed Air Supply Systems

Product Features: ? Small scale pressure pump with remarkably high pressure and flow rates ? Easy to transport ? Applicable for the supply of compressed air ? Long-term laboratory operations possible ? Low noise level ? Maintenance free ? Environmentally friendly ? Direct drive transmission ? Temperature protection for the motor ? Filter for dust and liquid particles ? Pressure gauge and controller ? CSA, CE, UL, PSE, FDA & TUV GS approved   Product Application: ? Widely used in laboratory environments with high standards on purity levels, such as: ? Fermentation tanks and bioreactors ? Gas chromatography ? Gas purging devices ? Driving compressed air sources Technical Data Model P520 P640 Power 92W × 2 AC 180W Mains Requirements 220-240V/50Hz 220-240V/50Hz Motion Type Automatic Motion?Preset Pressure 2.8bar (on) / 4.1 bar (off) Automatic Motion?Preset Pressure (adjustable) 4.1bar (on) / 5.5bar (off) Max. Flow Rate (L/min) 50 50 Ultimate Pressure (bar) 4.1 5.5 Motor Speed (rpm) 1400 1400 Weight (kg) 9.5 15.0 Gas Tank Volume (L) -- 5.5 Dimensions (L×W×H in mm) 265 × 265 × 225 370 × 335 × 315 Accessories Straight air hoses (3 m) Gas nozzle holder Gas container, pressure gauge, Pressure regulation valve, Liquids and dust filter, Straight air hoses (3 m) Outlet 1/8” PS 1/8” PS Noise Level (dB) 50 50 Order No. 167520-22 167640-22
Code : BioVac

BioVac Bio-Suction Systems

Bio-suction systems are especially designed for biochemical cultivation and the separation of culture fluids. It is an indispensable partner for a sterile laboratory bench and entails the following features. Oil-Free Vacuum Pump The System employs an oil-free vacuum pump, where no lubricant is needed and which is maintenance free. Moreover its noise level is very low. Convenience Suction of various liquids and a foot switch makes the system very convenient to use. Double Overflow Protection The waste bottle contains a floating ball and between the waste bottle and the vacuum pump a 0.2 μm PTFE disc filter is installed. These two safety measures can protect the system from liquid overflow and the liquid from entering the vacuum pump. High-Temperature and High-Pressure Sterilization Waste bottle and disc filter are resistant against high pressure steam sterilization. Product Application ? Waste liquid suction in cell cultivation ? All kinds of waste liquid suction in laboratory environments Technical Data Type BioVac 225 BioVac 235 BioVac 240 Vacuum Creation Method Diaphragm Pump Diaphragm Pump Piston Pump Power (W) 25 25 200 Ultimate Vacuum (mbar) 100 100 80 Max. Flow Rate (L/min) 25 35 40 Foot Switch No Yes Yes Weight (kg) 4.3 6.9 12 Dimensions (cm) 37 × 15 × 25 27 × 30 × 28 54 × 26 × 35 Order No. 167225-22 167235-22 167240-22   Ordering Information Order No. Description 167225-22 BioVac225 Bio-Suction System, AC220V / 50Hz 167235-22 BioVac235 Bio-Suction System, AC220V / 50Hz 167240-22 BioVac240 Bio-Suction System, AC220V / 50Hz 167200-31 1000 ml waste bottle, floating ball, sterilization 167200-32 2000 ml waste bottle, floating ball, sterilization 167200-33 3000 ml waste bottle, floating ball, sterilization 167200-35 PTFE disc filter with 37 mm diameter, 0.2μm pore size, applicable for BioVac 225 / 235 167200-36 PTFE disc filter with 73 mm diameter, 0.2μm pore size, applicable for BioVac 240 167200-37 Liquid filtration set 168021-01 1 m silicon tube 167200-39 Waste bottle clamp 167200-40 Foot switch for the BioVac 240 167200-41 Universal foot switch 167200-42 Single-branch suction head
