INSTRUMENTS

Code : M Series

Precision Balance

A top Quality series of Precision Balances that  combine  elegance  with  highly  reli- able measuring performance. Double case structure,  ergonomic keypad,  external  or internal  calibration.  Many  embedded  ad- vanced features make them perfect for use in  laboratory,  research  departments,  for- mulation and quality control applications. Features Electromagnetic force restoration weighing system External or automatic internal calibration LCD with backlight with adjustable contrast Round Glass windshield Plastic Protaction Cover Under hook weighing   Description  Model Capacity (g) Resolution (g) Pan (mm)  Repeatibility (g) Linearity (g) Response time (sec.) Verification (optional2) M External Calibration M223 220 0.001 110 0.0005 ± 0.002 ≤ 2 - M333 320 0.001 110 0.0005 ± 0.002 ≤ 2 - M523 520 0.001 110 0.001 ± 0.002 ≤ 2 - M723 720 0.001 110 0.001 ± 0.002 ≤ 2 - M1003 1000 0.001 110 0.001 ± 0.003 ≤ 3 - M1203 1200 0.001 110 0.001 ± 0.003 ≤ 3 - M1003D 500/1000 0.001/0.01 110 0.001/0.005 ± 0.001/ ± 0.01 ≤ 2 - M1203D 720/1200 0.001/0.01 110 0.001/0.005 ± 0.002/ ± 0.01 ≤ 2 - Internal Automatic Calibration M223i 220 0.001 110 0.0005 ± 0.002 ≤ 2 M M333i 320 0.001 110 0.0005 ± 0.002 ≤ 2 M M523i 520 0.001 110 0.001 ± 0.002 ≤ 2 M M723i 720 0.001 110 0.001 ± 0.002 ≤ 2 M M1003i 1000 0.001 110 0.001 ± 0.003 ≤ 3 - M1203i 1200 0.001 110 0.001 ± 0.003 ≤ 3 - M1003Di 500/1000 0.001/0.01 110 0.001/0.005 ± 0.001/ ± 0.01 ≤ 2 M M1203Di 720/1200 0.001/0.01 110 0.001/0.005 ± 0.002/ ± 0.01 ≤ 2 M

Analytical Balance

BEL Engineering s.r.l. (Italy) - HPB means High Performance Balances. This series includes Analytical Balances 0.0001g resolution that reach the highest measuring performance always combined with the unique italian BEL style.  HPB are equipped with BEL latest Monoblock weighing cell, developed by BEL R&D team, whose benefits are high stability against temperature changes and time, high integration, quick response thanks to reduced mass, overall reduction of total number of components.  HPB balances have -as standard- automatic internal calibration that allows always precise measurements, practically independent from environment temperature changes.  Analytical Balances of HPB series come with capacities (Max) 410g, 510g and 610g. All models are equipped with backlit LCD display or graphic display, a glass draft windshield that protects a large volume inner measuring chamber.  Each balance is equipped with RS232 output interface.  Features of the balance are: Selectable Measuring Units Piececounting Checkweighing Percentual Weighing GLP Date/Time Multi Languages Formulation Animal Weighing Density Determination (Solid and Liquid) Max Load Determination (Peak Hold) Description: Model Capacity (g) Resolution (g) Pan (mm)  Repeatibility (g) Linearity (g) Response time (sec.) Verification (optional2) M External Calibration MG124A 120 0.0001 80 0.0001 ± 0.0003 ≤ 4 - MG164A 160 0.0001 80 0.0001 ± 0.0003 ≤ 4 - MG214A 220 0.0001 80 0.0001 ± 0.0003 ≤ 4 - MG254A 250 0.0001 80 0.0001 ± 0.0003 ≤ 4 - MG314A 310 0.0001 80 0.0001 ± 0.0004 ≤ 4 - Internal Automatic Calibration MG124AI 120 0.0001 80 0.0001 ± 0.0003 ≤ 4 M MG164AI 160 0.0001 80 0.0001 ± 0.0003 ≤ 4 M MG214AI 220 0.0001 80 0.0001 ± 0.0003 ≤ 4 M MG254AI 250 0.0001 80 0.0001 ± 0.0003 ≤ 4 M MG314AI 310 0.0001 80 0.0001 ± 0.0004 ≤ 4 -
  • Download
Code : i-Thermo

Moisture Balances

?Why the i-Thermo Moisture Balances? Adopting two microprocessors, one for controlling all functions of the balance and the other for total control of the furnace heat, BEL Engineering came to realize the ideal equipment for moisture determination of raw materials and finished products in the food, cosmetic, dairy, pharmaceutical, chemical, ceramics and construction material industries etc. The philosophy to adopt two microprocessors in their Moisture Balances enabled BEL Engineering to introduce in the market a product with high performance at competitive cost. The i-Thermo Moisture Balance is the right choice since it provides great quality at competitive prices. The i-Thermo Moisture Balances are rugged instruments for moisture determination of raw materials and finished samples in the food, cosmetic, ceramics, agriculture, pharmaceutical and construction industries. The i-Thermo Moisture Balance has the following features: Halogen - Infrared lamp External Calibration LCD with backlight and adjustable contrast Time (1-99min) with 1 minute increments and autostop operating modules 5 drying programs can be stored Temperature Range: 35-160°C with 1°C increments Moisture, dry residue in percentage and ATRO indications Drying resolution 0.001% - 0.01% - 0.1% RS232 serial interface Plastic Protection Cover   i-Thermo Moisture Balance Calibration Data Model Capacity (g) Resolution (g) Pan (mm) Repeatibility (g) Linearity (g) Precision (2g) Response (Sec.) Weighing System i-Thermo A64M 60 0.0001 100mm Single Pans 0.0001 ±0.0003 0.18% ≤ 3 Electromagnet Force Restoration i-Thermo 163M 160 0.001 100mm Single Pans 0.001 ±0.003 0.18% ≤ 3 Electromagnet Force Restoration i-Thermo 163L 160 0.001 100mm Single Pans 0.001 ±0.003 0.20% ≤ 3 High Resolution Load Cell i-Thermo 62L 60 0.01 100mm Single Pans 0.01 ±0.03 0.50% ≤ 3 High Resolution Load Cell   i-Thermo Moisture Balance Technical Specifications Model Span Drift(+10..+30°C) L x W x H (mm) Power Supply Heater Weight (Kg) i-Thermo A64M ±3ppm/°C 345x215x235 110-230Vac, 50/60Hz; Output 24V 500mA 230 VAC 50/60Hz400 Watts 6.1 i-Thermo 163M ±4ppm/°C 345x215x236 110-230Vac, 50/60Hz; Output 9V 1.2A 230 VAC 50/60Hz400 Watts 6.1 i-Thermo 163L ±4ppm/°C 345x215x237 110-230Vac, 50/60Hz; Output 9V 1.2A 230 VAC 50/60Hz400 Watts 4.7 i-Thermo 62L ±4ppm/°C 345x215x238 110-230Vac, 50/60Hz; Output 9V 1.2A 230 VAC 50/60Hz400 Watts 4.7
  • Download
